ELECTRIC CHAIN HOIST EHC TYPE

ELECTRIC CHAIN HOIST EHC TYPE
Product Description



  • With suspension hook. push, geared or electric trolley.
  • Standard lift height 3 m, control cable 2.5m
  • Operating voltage 220-440V, 50/60Hz, 1-3 phase
  • Low voltage control 36V is standard.
  • High efficient energy-saving motor, asbestos free brake system.
  • Light weight, compact and solid body case.
  • Top and bottom hooks are fitted with safety latches as standard.
  • Drop forged steel suspension & load hooks are heat treated and fracture resistant. In case of dangerous overloading or abuse, the hook does not fracture but will slowly yield.
  • Solid chain bucket.
  • Super strong surface hardened chain
  • Limit switch devices fitted at both top & bottom ends, switch off power automatically to prevent load chain from running out.
  • Phase error relay, a specially designed current-post, prevents motor from running at incorrect wire connection.
  • Overload protection and thermal protection.





ELECTRIC CHAIN HOIST EHC TYPE
